34130A Series Compact High Power DC Electronic Load
60V, 1000A, 30KW

click to enlarge

Click here to view 34130A Series Introduction

Feature

With parallel function maximum power up to 320KW
Maximum up to 8 units master / slave parallel control
5 digit V/A/W Meter
High-speed measurement and communication transmission
Large LCD Display、setting values can be adjusted by rotary knob or push button
Voltage、Current and Watt value can be displayed simultaneously
Capable for Power Factor Correction (PFC) Test. (for 600V,1000V models)
OCP、OPP test function automatically
Power ON status can be set
CC, CR, CV, CP, CC+CV, CP+CV, Dynamic and Short operation mode
SHORT time setting
Protections against I,W,°C and over-voltage alert
Voltage meter display the polarity positive（”＋”）or negative（”－”）is selectable
Short, OCCP and OCDP function test for BMS protection board is provided (option)
Option：Emergency Stop and Analog Control are available
Optional Interface : GPIB、RS232、USB、LAN
0.7V @ 1000A is on Static condition, and the starting voltage must be greater than 5V, if on Dynamic condition that is 5V @ 1000A
New waveform generator plug in model 9923 adds user programmable battery dischargecurrent waveform simulation to Prodigit DC Loads


34105A	34110A	34115A	34120A
60V, 1000A, 5KW	600, 1000A, 10KW	600V, 1000A, 15KW	60V, 1000A, 20KW

34125A	34130A	34135A	34140A
60V, 1000A, 25KW	60V, 1000A, 30KW	60V, 1000A, 35KW	60V, 1000A, 40KW

34205A	34210A	34215A	34220A
600V, 160A, 5KW	600V, 320A,10KW	600V, 480A, 15KW	600V, 640A, 20KW

34225A	34230A	34235A	34240A
600V, 800A, 25KW	600V, 960A, 30KW	600V, 1120A, 35KW	600V, 1280A, 40KW

34305A	34310A	34315A	34320A
1000V, 50A, 5KW	1000V, 100A, 10KW	1000V, 150A, 15KW	1000V, 200A, 20KW

34325A	34330A	34335A	34340A
1000V, 250A, 25KW	1000V, 300A, 30KW	1000V, 350A, 35KW	1000V, 400A, 40KW
